GATE ECE 2004 | Question: 26

• recategorized by
586 views
0 0 votes

An AM signal is detected using an envelope detector. The carrier frequency and modulating signal frequency are $1 \; \mathrm{MHz}$ and $2 \; \mathrm{kHz}$ respectively. An appropriate value for the time constant of the envelope detector is

  1. $500 \; \mu \mathrm{sec}$
  2. $20 \; \mu \mathrm{sec}$
  3. $0.2 \; \mu \mathrm{sec}$
  4. $1 \; \mu \mathrm{sec}$

1 Answer

Answer:
← Previous · GATE ECE 2004 | Ques...Next → · GATE ECE 2004 | Ques...
← Previous in category · GATE ECE 2004 | Ques...Next in category → · GATE ECE 2003 | Ques...
Position:
Show:
Voting & Accepting an answer helps improve the community
